| Valve type | diaphragm type direct operated poppet |
|---|---|
| Valve operation | normally closed |
| Number of ports | 2 way |
| Fluid | air, water, DI water (pure water) |
Operating pressure range | -90kPa to 0.2MPa |
| Tube connection | tube inner diameter 3mmφ |
| Orifice diameter | 2mm |
| Cv | 0.065(Water) |
| Response time | 20ms or less(at pneumatic pressure） |
| Leakage | zero leakage, either external or internal(at water pressure） |
| Proof pressure | 0.3Mpa |
Ambient temperature | 5 to 50℃ |
Fluid temperature | 5 to 50℃(No condensation） |
Volume of valve chamber | 20μL or less |
Mounting orientation | free |
| Enclosure | IP40 or equivalent |
| Weight | 82g |
| Rated voltage | 12 VDC |
Allowable voltage fluctuation | ±10% of rated voltage |
Type of coil insulation | Class B(130℃) |
Power consumption(Current) | 3W(0.25A) |
| Coil switching noise | 70dB or less |
| Material for the wetted parts | body：PPS / diaphragm：EPDM |
