Perfect for tube clamping used in medical and diagnostic equipment.
By setting tube(s) at 2 clamping section,it is possible to use as 2 direction valve.
(of course it is possible to use as ON/OFF valve using one clamp).
| DC resistance | 40(Ω) |
|---|---|
| Service voltage | 12(V) |
| Fluid pressure | 0～150(kPa) |
| Power consumption | 3.6(W) |
| Heat resistance class | ClassE(120°C) |
| Insulation resistance | DC500V MEGA,Over 100MΩ |
| Dielectric strength | AC1000V, 50/60Hz, 1Minutes |
| Usable tube | I.D.1(mm) O.D.3(mm) Silicone rubber,PharMed |
| Type of lead wire | Heat-resistant vinyl electric wire (UL1007,AWG28,White) |
| Operating temperature | 0～50(°C) |
| Operating humidity | 30～90(%) |
| Storage temperature | -20～60(°C) |
| Storage humidity | 15～90(%) |
| Cautions) ●Data stated is average basic characteristic at early stage at 20 degrees centigrade. ●PharMed is a trademark of Norton Company. | |
