| Specifications | PSV-01T-020 | PSV-01T-120 | PSV-01T-180 |
|---|---|---|---|
| Orifice diameter | 0.2mm | 1.2mm | 1.8mm |
| Max. CV value | 0.001 | 0.03 | 0.042 |
| Operating pressure differential | ～0.6MPaG | ～0.35MPaG | ～0.15MPaG |
| Valve type | Direct operated solenoid valve | ||
| Valve operation | Normally closed | ||
| Standard compatible gas type | gases such as Air/O2/N2/H2/He/CO2/Ar | ||
| Gas-contact material | SUS/Brass/Electromagnetic SUS/FKM | ||
| Valve seal material | FKM | ||
| Body material | Brass | ||
| Ambient temperature | 0 ～ 50℃ | ||
| Mounting orientation | Unrestricted (coil upward recommended) | ||
| Connection diameter | M5 (Customization is possible. Please contact us) | ||
| Heat resistance class | A class (105℃) | ||
| Rated voltage | 24V | ||
| Coil resistance | 200Ω | ||
| Control Current Range | 0 ～ 95mA | ||
| Pressure resistance | 1.0MPa | ||
| Leak | 0.1cc/min less | ||
For improvement and other purposes, specifications, dimensions, etc. of this product are subject to change without notice.
